Binary Classification Neural Network from scratch in Numpy

In this tutorial we manually build the graph for a basic linear classifier. We will use the sigmoid activation function and the binary cross entropy loss function. We will train the model using standard gradient descent.

If you want to skip straight to the full code, you can find it on my GitHub here.

Up front, the important bits to know:

Binary Cross Entropy Loss Function

The forward pass of the binary cross entropy loss function is:

$L(\hat{y}, y) = -y \log(\hat{y}) - (1 - y) \log(1 - \hat{y})$

Intuitively, the ground truth $y$ is either 0 or 1, and the loss is the negative log likelihood of the predicted probability $\hat{y}$ given the ground truth. Sometimes this is normalized by the number of samples $1/N$ , but it’s not needed (and pytorch drops it).

Keeping in mind that

$\begin{array}{rl} \frac{\partial{\log(x)}}{\partial{x}} &= \frac{1}{x}\\ \frac{\partial{\log(1-x)}}{\partial{x}} &= -\frac{1}{1-x} \end{array}$

We compute the derivative of $L$ with respect to $\hat{y}$ step by step:

$\begin{array}{rl} \frac{\partial{L}}{\partial{\hat{y}}} &= -y (\frac{\partial{\log(\hat{y})}}{\partial{\hat{y}}}) - (1 - y) (\frac{\partial{\log(1-\hat{y})}}{\partial{\hat{y}}})\textup{ ; Substitute in log definitions}\\ &= -y (\frac{1}{\hat{y}}) - (1 - y) (- \frac{1}{1 - \hat{y}})\\ &= \frac{-y}{\hat{y}} + (1 - y) ( \frac{1}{1 - \hat{y}})\textup{ ; Simplify}\\ &= \frac{-y}{\hat{y}} + \frac{(1 - y)}{1 - \hat{y}}\\ &= \frac{-y(1 - \hat{y})}{\hat{y} (1 - \hat{y}) } + \frac{\hat{y}(1 - y)}{\hat{y}(1 - \hat{y})}\\ &= \frac{-y(1 - \hat{y}) + \hat{y}(1 - y) }{\hat{y}(1 - \hat{y})}\\ &= \frac{(-y - -y\hat{y}) + (\hat{y} - \hat{y}y) }{\hat{y} - \hat{y}^2}\\ &= \frac{\hat{y} -y }{\hat{y} - \hat{y}^2} \end{array}$

Sigmoid Activation Function

The forward pass of the sigmoid activation function is:

$\sigma(x) = \frac{1}{1 + e^{-x}}$

Keeping in mind that

$\begin{array}{rl} \frac{\partial{e^x}}{\partial{x}} &= e^x\\ \frac{\partial{e^{-x}}}{\partial{x}} &= -e^{-x}\\ \frac{\partial}{\partial{x}} \left(\frac{1}{x}\right) &= -\frac{1}{x^2} \end{array}$

We compute the derivative of $\sigma$ with respect to $x$ step by step:

$\begin{array}{rl} \frac{\partial{\sigma}}{\partial{x}} &= \frac{\partial}{\partial{u}} \cdot \frac{1}{u} \cdot \frac{\partial{u}}{\partial{x}}; u = 1 + e^{-x} \textup{ ; u substitution} \\ &= -\frac{1}{u^2} \cdot \frac{\partial{u}}{\partial{x}} \textup{ ; Substitute in fraction derivative} \\ &= -\frac{1}{(1 + e^{-x})^2} \cdot \frac{\partial}{\partial{x}} 1 + e^{-x} \\ &= -\frac{1}{(1 + e^{-x})^2} \cdot -e^{-x} \textup{ ; Substitute in natural exponent} \\ &= \frac{e^{-x}}{(e^{-x} + 1)^2} \end{array}$

Matrix Calculus

We will use the following notation for matrix calculus for the forward pass

$y = Wx + b$

Where $W$ is the weight matrix, $x$ is the input, $b$ is the bias, and $y$ is the output. The gradient of $y$ with respect to $W$ and $b$ is:

$\begin{array}{rl} \frac{\partial{y}}{\partial{W}} &= x^T\\ \frac{\partial{y}}{\partial{b}} &= 1 \end{array}$

Defining our numpy network layers

These partial definitions are all we need to write the code for the layer pieces. Note I am using dataclasses to make the code more readable, but these could be dictionaries or named tuples.

import numpy as np
from dataclasses import dataclass

@dataclass
class BinaryCrossEntropyLossPartials:
    output_wrt_yhat: np.ndarray


class BinaryCrossEntropyLoss:

    def forward(self, yhat: np.ndarray, y: np.ndarray):
        assert yhat.shape == y.shape, f"Shape difference: {yhat} vs {y}"
        assert np.all(1 >= yhat) and np.all(yhat >= 0), f"Domain error for yhat: {yhat}"
        assert np.all(1 >= y) and np.all(y >= 0), f"Domain error for y: {y}"
        # We drop the 1/len(yhat) factor to make the loss the same as torch's BCE loss
        loss = -(y * np.log(yhat) + (1 - y) * np.log(1 - yhat))
        # clamp the loss entries to at most 100 to avoid nan (and like torch's BCE loss)
        loss = np.clip(loss, -100, 100)
        return loss

    def backwards(
        self, yhat: np.ndarray, y: np.array
    ) -> BinaryCrossEntropyLossPartials:
        output_wrt_yhat = (yhat - y) / (yhat - yhat**2)

        return BinaryCrossEntropyLossPartials(output_wrt_yhat)


@dataclass
class LinearPartials:
    output_wrt_weight: np.ndarray
    output_wrt_bias: np.ndarray


class Linear:

    def __init__(self, in_features: int, out_features: int) -> None:
        self.in_features = in_features
        self.out_features = out_features
        self.weight = np.random.randn(out_features, in_features).astype(np.float32)
        self.bias = np.random.randn(out_features).astype(np.float32)

    def forward(self, x: np.ndarray) -> np.ndarray:
        return self.weight @ x + self.bias

    def backward(self, x: np.ndarray) -> LinearPartials:
        output_wrt_weight = x
        output_wrt_bias = np.ones_like(self.bias)
        return LinearPartials(output_wrt_weight, output_wrt_bias)


@dataclass
class SigmoidPartials:
    output_wrt_x: np.ndarray


class Sigmoid:

    def forward(self, x: np.ndarray) -> np.ndarray:
        return 1 / (1 + np.exp(-x))

    def backward(self, x: np.ndarray) -> SigmoidPartials:
        output_wrt_x = np.exp(-x) / ((np.exp(-x) + 1) ** 2)
        return SigmoidPartials(output_wrt_x)

Building our numpy network

Unlike PyTorch, we will manually build the graph for our network. We will use the following architecture:

$\hat{y} = \textup{Sigmoid}(\textup{Linear}())$

with the binary cross entropy loss function.

We define 3 methods for our network: forward, forward_loss, and update_weights. The forward method is the forward pass of the network, the forward_loss method is the forward pass of the network with the loss function, and the update_weights method is the backward pass of the network with the loss function and the update of the weights.

class MyNetwork:

    def __init__(self, in_features: int, out_features: int):
        self.in_features = in_features
        self.out_features = out_features

        self.linear1 = Linear(in_features, out_features)
        self.sigmoid = Sigmoid()
        self.loss = BinaryCrossEntropyLoss()

    def forward_loss(self, x: np.ndarray, y: np.ndarray):
        forward_out = self.linear1.forward(x)
        sigmoid_out = self.sigmoid.forward(forward_out)
        loss_out = self.loss.forward(sigmoid_out, y)
        return loss_out.sum()

    def update_weights(self, x: np.ndarray, y: np.ndarray, lr: float):
        forward_out = self.linear1.forward(x)
        sigmoid_out = self.sigmoid.forward(forward_out)

        loss_wrt_sigmoid = self.loss.backwards(sigmoid_out, y).output_wrt_yhat

        sigmoid_wrt_linear1 = self.sigmoid.backward(forward_out).output_wrt_x
        linear1_wrt_weight = self.linear1.backward(x).output_wrt_weight
        linear1_wrt_bias = self.linear1.backward(x).output_wrt_bias

        loss_wrt_linear1 = loss_wrt_sigmoid * sigmoid_wrt_linear1
        # Note: outer product because matrix multiplication!
        loss_wrt_weight = np.outer(loss_wrt_linear1, linear1_wrt_weight)
        loss_wrt_bias = loss_wrt_linear1 * linear1_wrt_bias

        self.linear1.weight = self.linear1.weight - lr * loss_wrt_weight
        self.linear1.bias = self.linear1.bias - lr * loss_wrt_bias

Note the tricky bits in here: we have to take the outer product between the partial loss_wrt_linear1 and linear1_wrt_weight because we are doing matrix multiplication. The weight matrix $W$ is of shape (out_features, in_features) and the gradient with respect to $W$ needs to be the same shape, and this shape is formed by the inner product of the input vector $x$ (the derivative of $Wx$ with respect to $W$ ) and the weights.

Training the network

To train the network, I give it some sample data. Note the rule for the data is the first element is an indicator variable for the ground truth label, making this easy data to fit.

# Set np seed
np.random.seed(42)

# fmt: off
sample_inputs =  [[1, 3, 5],    [1, 9, 5],    [1, 2, 5],    [0, 9, 5],    [0, 0, 5]]
sample_outputs = [[1, 0, 0, 0], [1, 0, 0, 0], [1, 0, 0, 0], [0, 0, 0, 0], [0, 0, 0, 0]]
# fmt: on

net = MyNetwork(3, 4)

lr = 0.01

for epoch_idx in range(2000):
    total_loss = 0
    for np_x, np_y in zip(sample_inputs, sample_outputs):
        np_x = np.array(np_x).astype(np.float32)
        np_y = np.array(np_y).astype(np.float32)
        total_loss += net.forward_loss(np_x, np_y)
        net.update_weights(np_x, np_y, lr)

    print(f"Epoch: {epoch_idx} Loss: {total_loss}")

and our training prints out the loss as it goes:

...
Epoch: 1997 Loss: 0.2139563336968422
Epoch: 1998 Loss: 0.21384888887405396
Epoch: 1999 Loss: 0.2137417010962963
